Nominal Diameter: 10"/262 inch/mm
Impedance: 8 Ohm
Minimum Impedance: 7.05 Ohm
Power Capacity AES ¹: 400 W
Power Capacity ²: 300 W
Program Power ³: 800 W
Sensitivity: (200-2000 Hz) 99.5 dB/W/m
Frequency Range: 80 - 2500 Hz
Voice Coil Diameter: 77 mm
Voice Coil Material: Aluminium
Voice Coil Former: Kapton™
Voice Coil Winding Depth: 15 mm
Magnet Gap Depth: 9 mm
Cone Material: Kevlar paper
Basket: Die cast aluminiumMagnet: Neodymium
Flux Density : 1.45 T
Resonance Frequency: 62.08 Hz
Mechanical Efficiency Factor (Qms): 10.61
Electrical Efficiency Factor (Qes): 0.216
Total Q (Qts): 0.212
Equivalent Air Volume (Vas ): 22.06 Litres
Diaphragm mass ind. airload (Mms): 42.72 grams
Voice Coil Resistance Re: 5.60 Ohms
Effective Diagram Area (Sd): 317.3 cm2
Peak Linear Displacement of Diaphragm (Xmax)*: ±5.25 mm
Mechanical Compliance of Suspension (Cms): 0.154 mm/N
BL Product (BL): 20.76 T.m
V.C. Inductance at 1 kHz (Le): 0.66 mH
