Faital Pro 18HP1022 - 18" Neodym Subwoofer 1000 W 8 Ohm
Faital Pro 18HP1022 - 18" Neodym Subwoofer 1000 W 8 Ohm
Datenblatt ...
- Minimum Impedance 6.5 Ohm
- Nominal Impedance 8 Ohm
- Nominal Power Handling 1,000 W
- Maximum Power Handling 2,000 W
- Sensitivity (1W/1m) 98 dB
- Frequency Range 35 - 1600 Hz
- Voice Coil Diameter 4", 100 mm
- Winding Material Copper
- Former Material Glass Fiber
- Winding Depth 0.91", 23 mm
- Magnetic Gap Depth 0.47", 12 mm
- Flux Density 1.3 T
- Resonant Frequency (fs) 35 Hz
- DC Resistance (Re) 5.4 Ohm
- BL Product (BL) 28 N/A
- Diaphragm Mass inc. Airload (Mms) 207 grams
- Mechanical Compliance of Suspension (Cms) 0.1 mm/N
- Rms 3.67 Kg/s
- Electromagnetic Q (Qes) 0.31
- Mechanical Q (Qms) 14.4
- Total Q (Qts) 0.3
- Compliance Equivalent Volume (Vas) 6.32 ft³, 179 dm³
- Surface Area of Cone (Sd) 174.22"², 1124 cm²
- Maximum Linear Excursion (Xmax)* 9.5 mm
- Xdamage** 17.5 mm
- Coil Inductance (Le) 1.75 mH
- Diaphragm mass (Mmd) 185.7 g
- Eta Zero 2.43 %
