Extrem leistungsfähiger 15 Zoll Subwofer auch in kleinem Volumen

Nominal Specifications

• Nominal Diameter 15", 380 mm
• Overall Diameter 15.47", 393 mm
• Bolt Circle Diameter 14.72", 375 mm
• Baffle Cutout Diameter 13.94", 354 mm
• Depth 7.65", 194.3 mm
• Flange and Gasket Thickness 0.54", 13.7 mm

Electrical Specifications

• Nominal Impedance 4 Ohm
• Nominal Power Handling*** 1000 W
• Maximum Power Handling**** 2000 W
• Sensitivity (1W/1m) 97 dB
• Frequency Range 40 - 2000 Hz
• Voice Coil Diameter 4", 100 mm
• Winding Material Kupfer
• Former Material Glass Fiber
• Winding Depth 1.14", 28.9 mm
• Magnetic Gap Depth 0.47", 12 mm
• Flux Density 1.22 T

THIELE & SMALL Parameters

• Resonant Frequency (fs) 40 Hz
• DC Resistance (Re) 2.9 Ohm
• BL Product (BL) 20.7 N/A
• Diaphragm Mass inc. Airload (Mms) 205.4 grams
• Mechanical Compliance of Suspension (Cms) 0.1 mm/N
• Rms 3.44 Kg/s
• Electromagnetic Q (Qes) 0.35
• Mechanical Q (Qms) 10.3
• Total Q (Qts) 0.34
• Compliance Equivalent Volume (Vas) 3.09 ft³, 87.5 dm³
• Surface Area of Cone (Sd) 120.9"², 780 cm²
• Maximum Linear Excursion (Xmax)* 12.45 mm
• Xdamage** 21 mm
